A critical factor for the HSK interface with manual tool change in turning machines or turrets as well as milling machines is the rigidity and change precision. Manual clamping systems from RÖHM achieve this via the compact force flow within a minimum amount of space.
1: Sealed, central cooling feed-through
2: Mounting flange in HSK-C or HSK-D for easy attachment
3: Set screw for actuation of the built-in clamping set
4: Built-in clamping set HSK-C or HSK-D
HSK-C clamping set
for tool shanks A/C/T; HSK 25-160
HSK-C clamping set with flange
for mounting on spindles, turrets, etc. for tool shanks A/C/T; HSK 25-160
The Lubritool lubrication tool from Röhm is for lubrication of your HSK clamping system.
